Commercial heating
Domestic hot water recirculation
Liquid:
Pumped liquid: Water
Liquid temperature range: -25 .. 110 °C
Selected liquid temperature: 60 °C
Density: 983.2 kg/m³
Technical:
Rated flow: 6.66 m³/h
Rated head: 7.072 m
TF class: 110
Approvals: AAA,EAC,RCM
Materials:
Pump housing: Cast iron
EN 1561 EN-GJL-200
ASTM 30 B
Impeller: Composite
PES+30% GF
Installation:
Range of ambient temperature: 0 .. 40 °C
Maximum operating pressure: 10 bar
Type of connection: G
Size of connection: 1 1/2 inch
Pressure rating for connection: PN 10
Port-to-port length: 180 mm
Electrical data:
Power input in speed 1: 280 W
Power input in speed 2: 340 W
Max. power input: 345 W
Mains frequency: 50 Hz
Rated voltage: 1 x 230 V
Current in speed 1: 1.3 A
Current in speed 2: 1.5 A
Current in speed 3: 1.52 A
Capacitor size – run: 8 µF
Enclosure class (IEC 34-5): X4D
Insulation class (IEC 85): H
Built-in motor protection: CONTACT
Others:
Terminal box position: 9H
Net weight: 6.3 kg
Gross weight: 7.03 kg
Shipping volume: 0.017 m³
Country of origin: DE
Custom tariff no.: 84137030
